Kubota Tedders

Kubota tedders help you produce high-quality crop, even under difficult weather circumstances. Ever-changing weather conditions often leave a very tight time window to prepare the crop. When the weather proves to be flexible, it is vital that your gear and equipment is just as flexible.

Key Features

  • Built for performance in even the toughest conditions
  • Reliable, robust and precise
  • High capacity machinery

About Kubota Tedders

Kubota TE Series

TE4000-10000

For delivering the best possible output in the most efficient way, it requires a tedder that is made for all conditions. You need an easy but also robust machine that gets the job done to your satisfaction.

Mounted tedders – CompactLine

Working width between 4.60 and 8.05m.

Mounted tedders – ProLine

Working width from 5.50 to 9.00m.

Mounted tedders – CompactLine

Working width between 4.60 and 8.05m.

Mounted tedders – ProLine

Working width from 5.50 to 9.00m.

Gearbox/Mainframe

CompactLine: maintenance-friendly gearbox

A strong reliable heart

Kubota ProLine tedders feature a uniquely designed self-contained rotor gearbox. The ProLine gearbox requires no maintenance, and is situated in an enclosed oilbath, set up to ensure permanent lubrication. No service or maintenance of the ProLine gearbox is needed. The gearboxes do not serve as part of the frame, but are bolted onto the fully welded mainframe. This ensures that no load and strain from frame or tine arm vibrations will be transmitted by the gearbox, adding to significantly longer lifetime.

The ProLine gearboxes feature reliable crown and pinion drives positioned in one housing. The main crown wheel in each gearbox is mounted directly to the casing by means of double bearing. The double bearings on both sides of the hexagonal drive shaft keeps the shaft securely in place, even when operating in heavy duty wet crop.

Heavy duty mainframe design

The Kubota tedders are built around a rugged new box section mainframe, made out of one piece of metal with only one welding seam – for maximum rigidity. The frame design is fully enclosed at the top edge for maximum strength – an exceptionally solid design, which allows the Kubota tedders to withstand the most severe loads.

Super-C tines

ProLine Super-C tines: Even spread – clean job

Kubota tedders help you produce high quality crop, even under difficult weather circumstances. Ever changing weather conditions often leave a very tight time window to prepare the crop. When the weather proves to be flexible, it is vital that your gear and equipment is just as flexible.

Take the lead in beating the weather

The Kubota tedders are the right tools to accomplish uniform and rapid drying action of the crop. The Kubota Super-C tines, working with generous overlap thanks to the rotor design, always leave an airy and evenly spread crop, speeding up the drying process, so you can chop or bale the crop in time. Kubota tedders allow you to instantly react to unpredictable weather conditions.

The Super-C tine

In order to produce high quality silage or hay, the crop must be spread evenly across the field to facilitate a uniform drying process. In addition soil contamination is a no go.

The symmetric Kubota Super-C tines of identical length efficiently pick up the crop and turn it for a very efficient crop flow. The crop is spread evenly and thrown over a wide distance, to ensure that the wet crop is placed on top of dry crop. Tines with same lengths has the added advantage that load is spread evenly on both tines, providing longer life time.

The Kubota Super-C tines are made of 10mm shot- peened spring steel. Spring diameter coils have 20% larger diameters than conventional designs for added service life, even when tedding large quantities of crop. Additionally optional tine saver clips are available.

Oscillation dampers

The Kubota oscillation dampers ensure excellent ground contour following and tedder flotation. The construction of the oscillation dampers results in a smooth and even distribution of the grass, due to the constant tine distance to the ground.

The distant linkage point means that it offers excellent running characteristics compared to conventional oscillation dampers. The fact that the linkage is positioned low on the headstock results in a more effective damping action during transport.
